DESI × CMB Lensing Field-Level Inference

Pipeline Blueprint & Implementation Roadmap

The scientific objective is to extract cosmological information using field-level inference on DESI galaxy clustering jointly with CMB lensing convergence maps from Planck and ACT.

Overview

Field-Level Inference Architecture

Figure: Complete field-level inference pipeline. The forward model (top) generates predictions from initial conditions δ_ini through N-body evolution (JAX-PM) to final density δ_final, which produces both galaxy overdensity δ_g and κ-map through ray-tracing. The MCLMC sampler compares these predictions with observed data (DESI LRG + Planck/ACT κ-map) to update the posterior distribution of cosmological parameters and the initial density field.

The pipeline proceeds through the following stages:

1. Initial Conditions ✅ (October 2025)

Generate 3D Gaussian random fields representing primordial density fluctuations in a periodic box. These serve as initial conditions for gravitational evolution.

Implementation: Power spectrum computation via jax_cosmo (Eisenstein–Hu transfer function); 3D field generation in Fourier space; validation through measured power spectra. Tests: tests/test_initial_conditions.py Notebook: notebooks/01_initial_conditions_demo.ipynb

Next step: Gravitational evolution using jaxpm to evolve δ(x, z_init) → δ(x, z_obs)

2. Gravitational Evolution ✅ (October 2025)

Evolve initial density fields forward in time using Lagrangian Perturbation Theory (LPT) and N-body particle-mesh methods with the BullFrog integrator.

Implementation: - Growth factor computations via jaxpm ODE solver - First and second-order LPT displacements - Full N-body evolution with BullFrog solver from diffrax - Particle-mesh force calculations

Tests: tests/test_evolution.py Notebook: notebooks/02_gravitational_evolution_demo.ipynb

Next step: Galaxy bias modeling and redshift-space distortions

3. Galaxy Bias Modeling ✅ (October 2025)

Transform evolved matter density fields into galaxy density fields using bias models and redshift-space distortions. Add observational noise to create realistic mock data.

Modules: desi_cmb_fli.bricks, desi_cmb_fli.nbody Implementation: - Kaiser model: Linear bias + RSD in Fourier space - Lagrangian bias expansion (LBE): Non-linear bias effects following Modi+2020 - Linear bias (b₁) - Quadratic bias (b₂) - Tidal shear bias (b_s²) - Non-local bias (b_∇²) - Redshift-space distortions from peculiar velocities - Observational noise (shot noise) modeling - Posterior sampling with Kaiser approximation

Tests: tests/test_model.py Notebook: notebooks/03_galaxy_bias_demo.ipynb

Next step: Field-level inference pipeline

4. Field-Level Inference ✅ (October 2025)

Full Bayesian inference pipeline for parameter estimation from synthetic and real data.

Module: desi_cmb_fli.model (FieldLevelModel) Implementation: - Probabilistic model: - Prior distributions for cosmology (Ωm, σ8) based on Planck18 - Prior distributions for bias parameters (b₁, b₂, b_s², b_∇²) - Prior on initial conditions (Gaussian random field) - Forward model pipeline: IC → evolution (LPT/Kaiser) → bias → observable - Data conditioning and model blocking - Kaiser posterior initialization for efficient MCMC warmup - NUTS or MCLMC sampler for parameter inference

Supporting modules: - desi_cmb_fli.metrics - Analysis metrics and power spectra - desi_cmb_fli.chains - Chain utilities and diagnostics - desi_cmb_fli.plot - Visualization tools - desi_cmb_fli.samplers - MCMC samplers (NUTS, MCLMC)

Tests: tests/test_model.py (11 tests covering model creation, prediction, conditioning, initialization) Notebook: notebooks/04_field_level_inference.ipynb - Complete demonstration with synthetic data

5. CMB Lensing Modeling ✅ (November 2025)

Computation of convergence κ from matter fields using Born approximation.

Module: desi_cmb_fli.cmb_lensing

Born Convergence (convergence_Born_mesh)

The Born projection converts each z-slice of the 3D matter mesh into an angular contribution to the convergence map κ. Each slice is reprojected from comoving to angular coordinates via a gnomonic (tangent-plane) projection using bilinear interpolation (map_coordinates(order=1, mode="wrap")).

Anti-aliasing: the accumulation is done in Fourier space with two per-shell corrections:

  1. Bilinear deconvolution: division by $\mathrm{sinc}^2(\ell\,\Delta x / 2\pi\chi)$ corrects the attenuation introduced by the bilinear interpolation kernel.
  2. Per-shell $\ell_{\max}$ filter: each shell at comoving distance $\chi$ only contributes angular modes $\ell < k_{\rm Nyq} \times \chi$ where $k_{\rm Nyq} = \pi/\Delta x$. This prevents 3D Nyquist-aliased power from the matter mesh from contaminating the angular spectrum.

The input density_field is pre-anti-aliased in 3D by paint_and_deconv (interlaced CIC + deconvolution + Fourier crop), so the 2D projection inherits the 3D anti-aliasing and adds its own angular-domain corrections.

The lensing kernel per slice is: $W_\kappa(\chi, a) = \frac{3}{2}\Omega_m\left(\frac{H_0}{c}\right)^2 \frac{\chi}{a} \cdot \frac{\chi_s - \chi}{\chi_s}$

Flat-Sky Diagnostic Projection (project_flat_sky)

A diagnostic-only function used by validation.py and quick_cl_spectra.py to project a 3D field (e.g. galaxy counts) onto a 2D angular map. Uses the same anti-aliasing scheme as convergence_Born_mesh (sinc² deconvolution + per-shell $\ell_{\max}$ filter in Fourier space).

AbacusSummit Kappa Extraction (prepare_abacus_kappa)

Downsamples a full-sky HEALPix κ map to the model's flat-sky grid: 1. hp.ud_grade to NSIDE 4096 (memory) 2. Gnomonic projection at $8\times$ oversampling 3. Fourier crop to target resolution (low-pass + downsample)

6. Joint Field-Level Inference ✅ (closure mode)

Joint inference on synthetic galaxy + CMB lensing data to constrain cosmology and initial conditions.

Script: scripts/run_inference.py

Joint Likelihood

The joint likelihood combines the galaxy number density likelihood with the CMB lensing convergence ($\kappa$) likelihood.

CMB Likelihood with Full Normalization: The CMB convergence likelihood is implemented as a Fourier-space Gaussian with proper log-determinant term: $$\frac{1}{T}\ln P(\kappa_{obs}|\kappa_{pred}) = -\frac{1}{2T}\sum_{\ell} \left[\frac{|\Delta\kappa_\ell|^2}{C_\ell} + \ln C_\ell\right]$$ where $C_\ell = N_\ell + C_\ell^{high-z}$ is the total variance (noise + cosmic variance from unmodeled high-z contribution). - The log-determinant term $\ln C_\ell$ was previously omitted because it is constant in galaxy-only mode (where $C_\ell = N_\ell$ fixed). - However, in taylor and exact high-z modes, $C_\ell^{high-z}$ depends on cosmological parameters ($\Omega_m, \sigma_8$), making the log-determinant parameter-dependent and required for correct posterior normalization.

Nyquist Frequency Filtering: Modes beyond 0.5 × Nyquist frequency are masked out in the CMB likelihood to avoid constraining with poorly-resolved scales. The fraction is set by NYQUIST_FRACTION = 0.5 in cmb_lensing.py. The Nyquist limit is computed as: $\ell_{Nyquist} = \frac{180° \times N_{pix}}{\mathrm{field_size_{deg}}}$ Only modes with $\ell \leq 0.5 \times \ell_{Nyquist}$ contribute to the likelihood (chi-squared and log-determinant terms).

Planck PR4 Noise: Incorporates realistic reconstruction noise using the official Planck PR4 $N_\ell$ spectrum.

High-z Analytical Marginalization

Accounts for the unmodeled high-redshift ($z > z_{box}$) lensing contribution by analytically marginalizing over the missing volume. - The theoretical convergence power spectrum ($C_\ell^{\kappa_{high-z}}$) is computed via jax_cosmo using the Non-Linear Matter Power Spectrum (Halofit). - This spectrum is added to the noise variance ($N_\ell + C_\ell^{\kappa_{high-z}}$) in the likelihood, correctly treating the high-z signal as an additional structured Gaussian variance (Cosmic Variance) rather than a fixed estimate.

High-Z Correction Strategy (high_z_mode)

Computing the high-z $C_\ell$ spectrum involves ~200k P(k) evaluations. We support three modes: - fixed: Caches $C_\ell^{high-z}$ at the fiducial cosmology. Fast, but mathematically inaccurate when sampled parameters drift far from fiducial. - taylor (Default): Uses a First-Order Taylor Expansion (Linear Emulator). The gradients $\partial C_\ell / \partial \Omega_m$ and $\partial C_\ell / \partial \sigma_8$ are precomputed at initialization. The likelihood applies a linear correction $C_\ell(\theta) \approx C_\ell(\theta_{fid}) + \nabla C_\ell \cdot \Delta \theta$. - exact: Fully recomputes the integral at every step. Extremely slow, used only for debugging/validation.

Technical Details

  • Angle Calibration (Gnomonic Projection): The angular field of view is calculated using exact trigonometry: $\theta = 2 \arctan(L_{trans} / 2\chi_{back})$.
  • This replaces the linear approximation ($\theta \approx L/\chi$) which introduced an error.
  • The Ray-Tracing module uses a tangent-plane projection ($x = \chi \tan(\theta)$) to accurately map the rectilinear simulation box onto the angular grid.
  • Even Mesh Dimensions (MCLMC Requirement): The mesh dimensions are automatically adjusted to ensure all axes have an even number of cells.
  • CIC Anti-Aliasing (model.paint_and_deconv): When paint_oversamp > 1.0, CIC painting uses interlaced order-2, deconvolution in Fourier space at oversampled resolution, then Fourier crop (chreshape) to final mesh shape.

Lightcone Implementation

  • Geometry convention: observer at $\chi=0$ (box face), simulation center at $\chi=L_z/2$.
  • Lightcone evolution: each particle/voxel evolves at local scale factor $a(\chi)$.
  • Galaxy model:
  • LPT uses particle-wise a.
  • Lagrangian bias terms are evaluated with local growth.
  • RSD uses local LOS and local a per particle.
  • Kaiser model: supports both snapshot (scalar a) and lightcone (a(\mathbf{x})), including LOS fields for curved-sky galaxy clustering.
  • CMB lensing: kernel is evaluated per slice as $W_\kappa(\chi,a)$ with slice-dependent scale factor.
  • Curved-sky scope: implemented for galaxy clustering only; CMB lensing remains flat-sky Born projection.
  • N-body scope: lightcone mode is implemented for LPT; N-body remains snapshot-only.

Observation Mode: Closure

Controlled by observation_mode in config.yaml (utils.ObservationMode enum):

closure: generates synthetic kappa_obs from truth_params via model.predict. Used for validation.

CMB-Only Mode

Parameter: galaxies_enabled (default: true)

Allows disabling galaxy likelihood to run CMB-only inference.

Example:

model:
  galaxies_enabled: false  # Disable galaxies
cmb_lensing:
  enabled: true  # Keep CMB

Implementation Details:

  • Initialization: Unlike joint/galaxy-only modes, CMB-only cannot use "reverse Kaiser" to initialize the density field from galaxy observations. Instead, the initial mesh is drawn from a random Gaussian field scaled by the prior power spectrum $P(k)$.

  • Adaptive Preconditioning: The Kaiser preconditioning automatically adapts to CMB-only mode: $$\text{scale} = \sqrt{1 + n_{gal}^{eff} \cdot b_E^2 \cdot P(k)}$$ where $n_{gal}^{eff} = n_{gal}$ if galaxies are enabled, and $n_{gal}^{eff} = 0$ otherwise.

In CMB-only mode ($n_{gal}^{eff} = 0$): - $\text{scale} = 1$ (no galaxy information) - $\text{transfer} = \sqrt{P(k)}$ (standard power spectrum prior)

This ensures the prior reflects the absence of direct density field constraints from galaxy counts, with information coming solely from the projected $\kappa$ map.

  • Optimizations: In CMB-only mode, the pipeline automatically:
  • Fixes bias parameters (b₁, b₂, b_s², b_∇²) to fiducial values (not sampled)
  • Skips galaxy position and Lagrangian bias expansion calculations for computational efficiency
  • Creates a dummy galaxy mesh for API consistency

Note: The positive Ω_m-σ_8 correlation observed in CMB-only mode is physical, arising from large-scale lensing geometry and working with h fixed (see figures/positive_correlation_diagnostic/).

Configuration

ACT DR6 Noise File

Location: data/N_L_kk_act_dr6_lensing_v1_baseline.txt

Contains the lensing reconstruction noise power spectrum N_ℓ^κκ for ACT Data Release 6. Format: two columns (ℓ, N_ℓ). Used in the CMB lensing likelihood to account for reconstruction noise.

Script: plot_cmb_noise_comparison.py - Compares ACT DR6 vs Planck PR4 noise spectra to visualize the improvement in reconstruction noise.

Artificial Noise Scaling

Parameter: cmb_noise_scaling (default: 1.0)

Multiplies the CMB noise N_ell by a factor to test sensitivity to noise level.

Example:

cmb_lensing:
  cmb_noise_scaling: 0.01  # Reduces noise by 100×

7. Joint FLI – Abacus Validation 🚧 (ongoing)

Joint inference using an external AbacusSummit N-body convergence map with a synthetic noise realization drawn from N_ℓ.

Required optional dependencies: pip install desi-cmb-fli[abacus] (adds healpy, asdf, abacusutils).

Controlled by observation_mode: abacus in config.yaml.

Abacus Mode: Kappa Map Selection and High-z Correction

Map selection. We use kappa_00047.asdf from AbacusSummit base c000_ph000, which has SourceRedshift = 1089.3 (CMB). Per the AbacusSummit lensing paper, each kappa_NNNNN file is a cumulative convergence map: the lensing kernel $W(\chi)$ uses $\chi_s = \chi(z_s)$ for the stated source redshift, but the N-body matter shells are only integrated up to the maximum simulation depth, which for the base-resolution lightcone is $z \approx 2.45$ ($\chi \approx 3990$ Mpc/h). Shells beyond this are not simulated.

Line-of-sight matching. When observation_mode: abacus, kappa_obs integrates matter to $\chi \approx 3990$ Mpc/h, not to $\chi_{\rm CMB}$. The FLI box depth (box_shape[2]) can be shallower than 3990 Mpc/h: kappa_pred only integrates to box_shape[2], and the full_los_correction adds the residual $C_\ell^{\rm high-z}$ in the likelihood variance for the missing line-of-sight depth $\chi_{\rm box} \to \chi_{\rm high-z_max}$.

chi_high_z_max parameter. Set in cmb_lensing config. If the box is shallower than $\chi_{\rm abacus}$, set chi_high_z_max: 3990.0 to cap the variance at the Abacus depth rather than extending it to $\chi_{\rm CMB}$.

8. Diagnostic & Analysis Tools

Theoretical Spectrum Comparison (quick_cl_spectra.py)

A diagnostic script to compare simulated or observed spectra against theoretical predictions computed via Limber integration with jax_cosmo. Supports both observation modes:

  • Closure mode: generates N independent LPT realizations from truth_params, accumulates spectra, plots mean ± std bands.
  • Abacus mode: loads the AbacusSummit kappa patch once, draws N independent noise realizations; uses a lightweight proxy model (geometry + N_ℓ only, without a full FieldLevelModel). Pass --no-smooth to disable the HEALPix band-limit, exposing gnomview aliasing (diagnostic only).
  • Spectra computed: $C_\ell^{\kappa\kappa}$ (obs and pred), $C_\ell^{gg}$, $C_\ell^{\kappa g}$.
  • Log-binned spectra: raw 2D spectra are log-binned via metrics.bin_cl_log (geometric bin centres, configurable bins/decade) and shown as error-bar markers alongside faded unbinned curves.
  • Noise Overlay: theory curves shown as Box, Box + high-z, and Box + high-z + N_ℓ dashed lines.

Resolution-Aware Limber Theory for $C_\ell^{gg}$ and $C_\ell^{\kappa g}$

The Limber integrals for galaxy and cross-spectra must account for the finite 3D resolution of the simulation mesh. The project_flat_sky function applies a per-shell cut $\ell_\text{max}(\chi) = k_\text{Nyq} \times \chi$ (where $k_\text{Nyq} = \pi/\Delta x$), zeroing modes that cannot be resolved by the 3D grid.

The fix is to integrate only shells satisfying $k_\perp = (\ell + 0.5)/\chi < k_\text{Nyq}$, i.e.\ $\chi > (\ell + 0.5)/k_\text{Nyq}$:

$$C_\ell^{gg} = \int_{\max(\chi_\text{min},\;(\ell+0.5)/k_\text{Nyq})}^{\chi_\text{max}} \frac{w_g^2(\chi)}{\chi^2}\,P!\left(\frac{\ell+0.5}{\chi}\right)d\chi$$

This is implemented via the k_nyq parameter in compute_theoretical_cl_gg and compute_theoretical_cl_kg (cmb_lensing.py). The script quick_cl_spectra.py computes k_nyq_mesh = π/Δx from the mesh geometry and passes it automatically. The uncorrected (full-resolution) theory is shown as a dotted reference line on the $C_\ell^{gg}$ panel.

Poisson Shot Noise in $C_\ell^{gg}$

The measured galaxy auto-spectrum includes a Poisson white-noise floor not present in the Limber signal theory or in the cross-spectrum $C_\ell^{\kappa g}$. For $N_\text{gal}$ discrete tracers over a solid angle $\Omega_\text{sky}$ the shot-noise level is constant in $\ell$:

$$N_\ell^{\text{shot}} = \frac{\Omega_\text{sky}}{N_\text{gal}} = \frac{(L_x / \chi_\text{center})^2}{\bar{n} \cdot L_x L_y L_z}$$

where $\bar{n}$ is model.gxy_density [(h/Mpc)³] and the denominator is the total number of simulation particles. The script quick_cl_spectra.py computes this level analytically, prints it at run time, and overlays three theory curves on the galaxy panel: the resolution-aware Limber signal alone (--), the signal plus shot noise (-.), and a horizontal flat line marking $N_\ell^{\text{shot}}$ (:). The diagnostic table prints both ratio (signal only) and ratio+shot columns. The cross-spectrum $C_\ell^{\kappa g}$ is unaffected because the kappa and galaxy fields are independent in the noise, so the shot-noise contribution vanishes in the cross-correlation.

Fisher Information Analysis (analyze_fisher_scales.py)

Computes Fisher information matrices to compare the constraining power of galaxies vs CMB lensing separately:

  • Separate Sensitivities: Evaluates $\partial C_\ell / \partial \theta$ for each observable (galaxy auto-spectrum, CMB lensing spectrum)
  • Implementation Note (2026-02): Uses model.nell_grid for CMB noise, model.gxy_density for $\bar n$, and enables galaxies via model.galaxies_enabled in cfg['model'].
  • Exact formulas used in the script:
  • CMB lensing (2D Fourier pixels, masked): with $$M = {\ell: 20 < \ell \le 0.5\,\ell_{Nyq},\ \mathrm{finite}(\partial_{\Omega_m}C_\ell, C_\ell, N_\ell)},$$ the script computes $$F_{\Omega_m\Omega_m}^{\mathrm{CMB}} = \sum_{p\in M} \frac{1}{2}\left(\frac{\partial C_p/\partial\Omega_m}{C_p+N_p}\right)^2,$$ and $$\sigma(\Omega_m){\mathrm{CMB}} = \left(F{\Omega_m\Omega_m}^{\mathrm{CMB}}\right)^{-1/2}.$$
  • Galaxy clustering (Gaussian + shot noise, FKP weight): with $P_N=1/\bar n$ and $P_{gg}(k)=b_E^2P_{mm}(k)$, the script uses the discrete finite-volume FFT sum on the anisotropic box lattice: $$F_{\Omega_m\Omega_m}^{\mathrm{gxy}} = \frac{1}{2}\sum_{\mathbf{k}\in\mathcal{K},\,\mathbf{k}\neq0}\left[\frac{\bar n P_{gg}(k)}{1+\bar n P_{gg}(k)}\right]^2\left[\frac{\partial\ln P_{gg}(k)}{\partial\Omega_m}\right]^2,$$ where $\mathcal{K}$ is the exact set of discrete FFT modes $k_i=2\pi\,\mathrm{fftfreq}(N_i,d=L_i/N_i)$. $$\sigma(\Omega_m){\mathrm{gxy}} = \left(F{\Omega_m\Omega_m}^{\mathrm{gxy}}\right)^{-1/2}.$$
  • Parameter Constraints: Computes Fisher matrices and marginal uncertainties for $\Omega_m$ and $\sigma_8$
  • Information Comparison: Quantifies the relative information from each probe at different noise levels

Run Analysis and Comparison

analyze_run.py - Analyze a single inference run: - Merges batch outputs into a single chain file - Computes convergence diagnostics (R-hat, ESS) - Generates corner plots and trace plots; in abacus mode, uses abacus_truth_params as corner-plot markers instead of truth_params - Supports custom burn-in and chain exclusion

compare_runs.py - Compare multiple runs with GetDist: - Triangle plots comparing posterior distributions - Automatic constraint computation (mean ± std) - Per-run burn-in and chain filtering - Customizable labels and output paths

Usage examples:

# Analyze single run with 20% burn-in, excluding chains 0 and 2
python scripts/analyze_run.py --run_dir outputs/run_001 --burn_in 0.2 --exclude_chains 0 2

# Compare three runs
python scripts/compare_runs.py outputs/run_001 outputs/run_002 outputs/run_003 \
    --labels "Galaxies Only" "CMB Only" "Joint" --burn_ins 0.2 0.2 0.2

Kappa Map Visualization (plot_kappa_maps.py)

Runs a single forward-model realization and displays the κ maps: - Closure mode: shows κ observed (= pred + noise), κ predicted (noiseless), and galaxy density projected (if galaxies_enabled). - Abacus mode: shows Abacus κ + noise and Abacus κ (noiseless).

Uses the same config as run_inference.py.

Benchmarking and Validation

benchmark_highz_cl_modes.py - Benchmark precision and performance of high-z correction modes (fixed/taylor/exact) across different grid resolutions.

test_omega_m_effect.py - Validates the positive $\Omega_m$-$\sigma_8$ correlation in CMB-only mode by testing the effect of $\Omega_m$ on lensing power spectrum.

plot_lensing_fraction.py - Computes the fraction of total CMB lensing signal captured by the simulation box as a function of redshift depth.

Energy Variance Diagnostics

The MCLMC sampler's performance is critically dependent on the energy variance parameter (desired_energy_var in config.yaml). The script run_inference.py implements automatic diagnostics after warmup:

  1. Per-Chain Energy Variance: After the first sampling batch, the script reports MSE/dim for each chain individually.
  2. Ratio Check: Compares the actual energy variance to the desired value. A ratio $< 2\times$ is considered acceptable.
  3. Tuning Guidance: If the ratio is too high, reduce desired_energy_var in config.yaml. Values around 5e-8 to 5e-7 work well for runs with realistic noise levels; for reduced-noise runs (cmb_noise_scaling: 0.01) use 5e-9 or lower.

Next Steps

  1. Implement joint analysis of the abacus galaxy + CMB lensing dataset (currently just implemented for cmb lensing).
  2. Implement survey selection function and masking to enable realistic analysis of real data with non-uniform coverage and complex geometry.
  3. Implement proper Fisher forecast comparison between galaxies and CMB lensing to quantify the relative information content of each probe (talk to Arnaud De Mattia).
  4. Compare the analysis to a standard power spectrum analysis to validate the field-level inference results (talk to Arnaud De Mattia).
  5. Implement curved-sky for CMB lensing to enable accurate modeling of large angular scales (talk to Wassim Kabalan) and directly take an HEALPix κ-map as input.
  6. Infer $b_1 \times σ_8$ instead of $b_1$ to break degeneracies and improve constraints (talk to Hugo Simon).
  7. Measure the runtime of a single model evaluation to assess the additional computational cost of the CMB lensing modeling and likelihood compared to the galaxy-only pipeline.
  8. Implement the taylor expansion for the high-z correction at the order two (quadratic) to improve accuracy when sampling far from the fiducial cosmology.
  9. Preconditioning for Joint Inference - Incorporate CMB lensing terms into the MCLMC/MAMS preconditioning matrices for improved sampling efficiency.
  10. Field-Level Inference on Real Data - Application to joint DESI LRG $\times$ Planck/ACT $\kappa$-map datasets.

Implementation details will be documented as development progresses.
